Cartridge 35mm

35GR
35GF
35SR
35SF
35SR-3S
35SF-3S
35LR
35LF
35JR
35JF
35SMR
35SMF
35ER
35VR
35EF
35ER,A
35EF,A
35MR
35MF
35AF-H

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	90˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	90˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	90˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	360˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	360˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	15~19 ℓ/min
Flow Rate (at 2bar)	20~28 ℓ/min
Flow Rate (at 3bar)	29~35 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	100˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	15~19 ℓ/min
Flow Rate (at 2bar)	20~28 ℓ/min
Flow Rate (at 3bar)	29~35 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	180˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	60˚/30˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	7.5~8.5 ℓ/min
Flow Rate (at 2bar)	10.5~12 ℓ/min
Flow Rate (at 3bar)	13.5~15 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	60˚/30˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	7.5~8.5 ℓ/min
Flow Rate (at 2bar)	10.5~12 ℓ/min
Flow Rate (at 3bar)	13.5~15 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	60˚/30˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	7.5~8.5 ℓ/min
Flow Rate (at 2bar)	10.5~12 ℓ/min
Flow Rate (at 3bar)	13.5~15 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	60˚/30˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	7.5~8.5 ℓ/min
Flow Rate (at 2bar)	10.5~12 ℓ/min
Flow Rate (at 3bar)	13.5~15 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	45˚/45˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	0.5 kgf
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	25˚
Max. Turning Angle	45˚/45˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	0.5 kgf
Max. Temperature	90 ˚C
Max. Noise Level	15~18db
Flow Rate (at 1bar)	12~13 ℓ/min
Flow Rate (at 2bar)	17~19 ℓ/min
Flow Rate (at 3bar)	20~28 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)

PRODUCT IMAGE

PRODUCT SPECIFICATION

Max. Opening Angle	20˚
Max. Turning Angle	90˚
Nut Torque	10~11Nm
Water Resistance Pressure	Max. 35bar
Working Torque	Max. 0.5 Nm
Max. Temperature	90 ˚C
Flow Rate (at 1bar)	7.5~8.5 ℓ/min
Flow Rate (at 2bar)	11~12 ℓ/min
Flow Rate (at 3bar)	14~15 ℓ/min
Endurance Test	500,000 cycle

Dimensions (in mm)
